Canadian Solar CS6W-570T // Canadian Solar 570W Solar Panel // TOPCon 144 Cells
Manufacturer
Canadian Solar
Manufacturer Code
CS6W-570T
Junction box
IP68, 3 bypass diodes
Cable cross-section size
4 mm² (IEC), 12 AWG (UL)
Brand
Canadian Solar
Weight
27.6 kg
Show more
Offer from supplier:
Country of dispatch:
Destination countries:
Availability:
Payment methods recommended by merXu:
Alternative payment methods:
Manufacturer
Canadian Solar
Manufacturer Code
CS6W-570T
Junction box
IP68, 3 bypass diodes
Cable cross-section size
4 mm² (IEC), 12 AWG (UL)
Brand
Canadian Solar
Weight
27.6 kg
Short-circuit current
13.81A
Maximum power output
570W
Connectors
T6 or MC4-EVO2 or MC4-EVO2A
Power tolerance
0+10 Wp
Product
Canadian Solar 570
Number of cells
144 (2 x (12 x 6))
Manufacturer tier
Tier 1
NOCT (Nominal Operating Cell Temperature)
41ºC±3ºC
Maximum power current
13.35A
Efficiency
21.1%
Maximum power voltage
42.7V
Solar panel type
Mono Crystalline PERC
Dimensions
2278 x 1134 x 30 mm
Open-circuit voltage
51.8V
CANADIAN SOLAR 570W
TIER 1 MANUFACTURER SOLAR PANEL
ELECTRICAL PARAMETERS
Maximum Power (Pmax/W): 570W
Maximum Power Voltage (Vmpp/V): 42.7 V
Maximum Power Current (Impp/A): 13.35 A
Open-Circuit Voltage (Voc/V): 51.8 V
Short-Circuit Current (Isc/A): 13.81 A
Module Efficiency (%): 21.1 %
Power Tolerance: 0+10 Wp
NOCT: 41ºC±3ºC
Values at Standard Test Conditions STC: (AM 1.5, Irradiance 1,000 W/m2, Cell Temperature 25ºC)
SPECIFICATIONS
Cell Type: Mono Crystalline PERC
Number of cells: 144[2 X (12 X 6)]
Weight: 27.6 kg
Dimensions: 2278 ˣ 1134 ˣ 30 mm
Cable cross section size: 4 mm² (IEC), 12 AWG (UL)
Connectors: T6 or MC4-EVO2 or MC4-EVO2A
Junction Box: IP68, 3 bypass diodes
